Connector Jack DC Male

The Connector Jack DC Male is designed for reliable power connections in electronic devices. Its durable construction ensures stable conductivity and long-lasting performance, making it ideal for professional applications requiring secure and efficient DC power input. Compatible with a variety of equipment, this connector provides a precise fit to maintain consistent electrical contact.

Product features

Gender & Type Female Jack
Standard sizes include: 5.5mm × 2.1mm (most common), 5.5mm × 2.5mm, 3.5mm × 1.35mm (smaller devices), 6.5mm × 3.0mm (higher power applications)
Polarity, Center Positive (+) (most common) – Inner sleeve is positive, outer is negative, Center Negative (–) – Less common, used in some audio/video equipment.
Typically supports 5V to 24V DC, depending on application.
Current handling: 1A to 5A+ (varies by size and build quality).
Panel Mount: Screws into an enclosure (common in DIY projects).
PCB Mount: Soldered directly onto a circuit board.
Wire Lead: Connects via wires for flexible installation.

Best uses for

Routers & Modems (e.g., TP-Link, Netgear)
LCD Monitors & TVs (for external power adapters)
Audio Equipment (speakers, amplifiers, mixers)
Printers & Scanners (some models)
CCTV Cameras (for power supply from a DC adapter)
DVR/NVR Systems
Arduino & Raspberry Pi Projects (external power input)
Custom Power Supplies (for breadboards & test circuits)
LED Strips & Lighting Controllers
Lab Equipment (oscilloscopes, signal generators)
Medical Devices (small diagnostic tools)
Power Tools & Battery Chargers
Car Accessories (dash cams, inverters, coolers)
Portable Speakers & Radios
GPS Devices
Stage Lighting & DJ Equipment (prevents accidental unplugging)
Outdoor Electronics (weatherproof enclosures)

What's in the box

Connector Jack DC Male (1x)
